Danfoss VLT Flow Drive FC 111 - 4.3.2 Harmonic Filters

T4
(380–
480 V
AC)
0.37–1.5
(0.5–2.0)
2.2–4.0
(3.0–5.4)
5.5–7.5
(7.5–10)
11–15
(15–20)
18.5–22
(25–30)
30 (40)
37–45
(50–60)
55 (75)
75 (100)
90 (125)
Description
LCP
(1)
132B0200
LCP
panel
mount-
ing kit
includ-
ing 3 m
(9.8 ft)
cable
132B0201
Decou-
pling
plate
132B0202
132B0202
132B0204
132B0205
132B0205
132B0207
132B0242
132B0208
132B0243
132B0209
IP21
option
132B0212
132B0213
132B0214
132B0215
132B0216
132B0217
132B0218
132B0219
1
For IP20 units, LCP is ordered separately.
4.3.2 Harmonic Filters
Table 26: AHF Filters (5% Current Distortion)
3x380–480 V 50 Hz
Power [kW (hp)]
Drive input cur-
rent continuous
[A]
Default switching
frequency [kHz]
THDi level [%]
Order number filter
IP00
Code number filter
IP20
22 (30)
41.5
4
4
130B1397
130B1239
30 (40)
57
4
3
130B1398
130B1240
37 (50)
70
4
3
130B1442
130B1247
45 (60)
84
3
3
130B1442
130B1247
55 (74)
103
3
5
130B1444
130B1249
75 (100)
140
3
4
130B1445
130B1250
90 (120)
176
3
4
130B1445
130B1250
Table 27: AHF Filters (10% Current Distortion)
3x380–480 V 50 Hz
Power [kW (hp)]
Drive input cur-
rent continuous
[A]
Default switching
frequency [kHz]
THDi level [%]
Order number filter
IP00
Code number filter
IP20
22 (30)
41.5
4
6
130B1274
130B1111
30 (40)
57
4
6
130B1275
130B1176
37 (50)
70
4
9
130B1291
130B1201
