Danfoss VLT Flow Drive FC 111 Design Guide

4 Selection and Ordering
4.1 Type Code
A type code defines a specific configuration of the drive. Use the following illustration to create a type code string for the desired
configuration.
F
C
- P
T
H
e30bu797.10
X S A B C X X X X
1
2
3
4
5
6
7
8
9
10
11 12 13
14
15 16 17
18
19 20 30 22 21 23 27 25 24 26 28 29 31 37 36 35 34 33 32 38 39
X
1
D
1
1
X
X
X
X X
X
X X X
Illustration 35: Type Code
Table 20: Type Code Description
Description
Position
Possible choice
Product group & FC series
1–6
FC 111
Power rating
7–10
0.37–315 kW (0.5–450 hp) (PK37-P315)
Number of phases
11
3 phases (T)
Mains voltage
11–12
T4: 380-480 V AC
Enclosure
13–15
E20: IP20/chassis
P20: IP20/chassis with back plate
RFI filter
16–17
H1: RFI filter class A1/B
H2: RFI filter class A2
H3: RFI filter class A1/B (reduced cable length)
H4: RFI filter class A1
Brake
18
X: No brake chopper included
Display
19
A: Alpha numeric local control panel
X: No local control panel
Coating PCB
20
X: No coated PCB
C: Coated PCB
Mains option
21
X: No mains option
Adaptation
22
X: No adaptation
Adaptation
23
X: No adaptation
Software release
24–27
SXXXX: Latest release - standard software
Software language
28
X: Standard
A options
29–30
AX: No A options
B options
31–32
BX: No B options
C0 options MCO
33–34
CX: No C options
C1 options
35
X: No C1 options
C option software
36–37
XX: No options
AJ363928382091en-000101 / 130R0983 | 45Danfoss A/S © 2021.04
Selection and Ordering
VLT® Flow Drive FC 111
Design Guide
