1
Mains
2
Relays
3
Ground
4
Motor
6.4.4 Relays and Terminals on Enclosure Size H8
1
2
3
4
98
97
96
99
95
93
92
91
L1
L1
L1
U
V
w
e30bb764.10
Illustration 51: Enclosure Size H8 IP20, 380–480 V, 90 kW (125 hp)
1
Mains
2
Relays
3
Ground
4
Motor
AJ363928382091en-000101 / 130R098368 | Danfoss A/S © 2021.04
Electrical Installation
Considerations
VLT® Flow Drive FC 111
Design Guide
