Danfoss VLT Flow Drive FC 111 Design Guide

Table 33: Power Ratings, Weights, and Dimensions H13–H14
Enclosure Size
H13
H14
IP class
IP20
IP20
Power [kW (hp)]
3x380–480 V
110–160
(150–250)
200–315
(300–450)
Height [mm (in)]
A
889 (35.0)
1096 (43.1)
A
(1)
909 (35.8)
1122 (44.2)
a
844 (33.2)
1051 (41.4)
Width [mm (in)]
B
250 (9.8)
350 (13.8)
b
180 (7.1)
280 (11.0)
b1
200 (7.9)
271 (10.7)
Depth [mm (in)]
C
375 (14.8)
375 (14.8)
Mounting hole [mm (in)]
D
11 (0.4)
11 (0.4)
Center of gravity [mm (in)]
E
128 (5.0)
176 (6.9)
F
495 (19.5)
611 (24.1)
G
148 (5.8)
148 (5.8)
Maximum weight kg (lb)
98 (216)
164 (362)
1
Including decoupling plate.
The dimensions are only for the physical units.
5.2 Mechanical Installation H1-H8
5.2.1 Side-by-side Installation
The drive can be mounted side by side but requires the clearance above and below for cooling.
Table 34: Clearance Required for Cooling
Power [kW (hp)]
Clearance above/below [mm (in)]
Size
IP class
3x380–480 V
H1
IP20
0.37–1.5 (0.5–2.0)
100 (4)
H2
IP20
2.2–4.0 (3.0–5.4)
100 (4)
H3
IP20
5.5–7.5 (7.5–10)
100 (4)
H4
IP20
11–15 (15–20)
100 (4)
H5
IP20
18.5–22 (25–30)
100 (4)
H6
IP20
30–45 (40–60)
200 (7.9)
H7
IP20
55–75 (70–100)
200 (7.9)
H8
IP20
90 (125)
225 (8.9)
AJ363928382091en-000101 / 130R0983 | 55Danfoss A/S © 2021.04
Mechanical Installation
Considerations
VLT® Flow Drive FC 111
Design Guide
