Danfoss VLT Flow Drive FC 111 - Page 54

Enclosure Size
H5
H6
H7
H8
a
314 (12.4)
495 (19.5)
521 (20.5)
631 (24.8)
Width [mm (in)]
B
150 (5.9)
239 (9.4)
313 (12.3)
375 (14.8)
b
120 (4.7)
200 (7.9)
270 (10.6)
330 (13)
Depth [mm (in)]
C
255 (10)
242 (9.5)
335 (13.2)
335 (13.2)
Mounting hole [mm (in)]
d
12.6 (0.50)
–
–
–
e
7 (0.28)
8.5 (0.33)
8.5 (0.33)
8.5 (0.33)
f
8.5 (0.33)
15 (0.6)
17 (0.67)
17 (0.67)
Maximum weight kg (lb)
9.5 (20.9)
24.5 (54)
36 (79)
51 (112)
1
Including decoupling plate.
e30bu775.10
C
D
b1
B
b D
A
a
E
F
G
(1) (2)
(3)
Illustration 41: Dimensions, Enclosure Sizes H13–H14
1
Front view
2
Side view
3
Back view
AJ363928382091en-000101 / 130R098354 | Danfoss A/S © 2021.04
Mechanical Installation
Considerations
VLT® Flow Drive FC 111
Design Guide
