Enclosure type C1/C2 IP 21/Type 1, IP55/Type 12, IP66/12
Enclosure type C3/C4 IP20/Chassis
Enclosure type D1/D2/E1 IP21/Type 1, IP54/Type12
Enclosure type D3/D4/E2 IP00/Chassis
Enclosure type F1/F3 IP21, 54/Type1, 12
Enclosure type F2/F4 IP21, 54/Type1, 12
Enclosure kit available ≤ enclosure type D
IP21/NEMA 1/IP 4
X
on top of enclosure
Vibration test enclosure A, B, C 1.0 g
Vibration test enclosure D, E, F 0.7 g
Relative humidity 5% - 95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60068-2-43) H
2
S test
class Kd
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature (at 60 AVM switching mode)
- with derating max. 55° C
1)
- with full output power of typical EFF2 motors (up to 90% output current) max. 50 ° C
1)
- at full continuous FC output current max. 45 ° C
1)
1)
For more information on derating see the Design Guide, section on Special Conditions.
Minimum ambient temperature during full-scale operation 0 °C
Minimum ambient temperature at reduced performance - 10 °C
Temperature during storage/transport -25 - +65/70 °C
Maximum altitude above sea level without derating 1000 m
Maximum altitude above sea level with derating 3000 m
Derating for high altitude, see section on special conditions
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions!
Control card performance:
Scan interval : 5 ms
Control card, USB serial communication:
USB standard 1.1 (Full speed)
USB plug USB type B “device” plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is
not galvanically isolated from protection earth. Use only isolated laptop/PC as connection to the USB connector
on frequency converter or an isolated USB cable/converter.
8 General Specifications and Troubleshooting VLT
®
HVAC Drive Design Guide
172
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark
8
