Danfoss VLT HVAC Design Guide

4.2 Ordering Numbers
4.2.1 Ordering Numbers: Options and Accessories
Type Description Ordering no. Comments
Miscellaneous hardware I
DC link connector
Terminal block for DC link connnection on A2/A3 130B1064
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottomA2 130B1122
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottomA3 130B1123
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottom B3 130B1187
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottom B4 130B1189
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottom C3 130B1191
IP 21/4X top/TYPE 1 kit IP21/NEMA1 Top + bottom C4 130B1193
IP21/4X top IP21 Top Cover A2 130B1132
IP21/4X top IP21 Top Cover A3 130B1133
IP 21/4X top IP21 Top Cover B3 130B1188
IP 21/4X top IP21 Top Cover B4 130B1190
IP 21/4X top IP21 Top Cover C3 130B1192
IP 21/4X top IP21 Top Cover C4 130B1194
Panel Through Mount Kit Enclosure, frame size A5 130B1028
Panel Through Mount Kit Enclosure, frame size B1 130B1046
Panel Through Mount Kit Enclosure, frame size B2 130B1047
Panel Through Mount Kit Enclosure, frame size C1 130B1048
Panel Through Mount Kit Enclosure, frame size C2 130B1049
Profibus D-Sub 9 Connector kit for IP20 130B1112
Profibus top entry kit Top entry kit for Profibus connection - D + E enclosures 176F1742
Terminal blocks Screw terminal blocks for replacing spring loaded terminals
1 pc 10 pin 1 pc 6 pin and 1 pc 3 pin connectors 130B1116
Backplate A5 IP55 / NEMA 12 130B1098
Backplate B1 IP21 / IP55 / NEMA 12 130B3383
Backplate B2 IP21 / IP55 / NEMA 12 130B3397
Backplate C1 IP21 / IP55 / NEMA 12 130B3910
Backplate C2 IP21 / IP55 / NEMA 12 130B3911
Backplate A5 IP66 130B3242
Backplate B1 IP66 130B3434
Backplate B2 IP66 130B3465
Backplate C1 IP66 130B3468
Backplate
C2 IP66 130B3491
LCP's and kits
LCP 101 Numerical Local Control Panel (NLCP) 130B1124
LCP 102 Graphical Local Control Panel (GLCP) 130B1107
LCP cable Separate LCP cable, 3 m 175Z0929
LCP kit Panel mounting kit including graphical LCP, fasteners, 3 m cable and gasket 130B1113
LCP kit Panel mounting kit including numerical LCP, fasteners and gasket 130B1114
LCP kit Panel mounting kit for all LCPs including fasteners, 3 m cable and gasket 130B1117
LCPkit Front mounting kit, IP55 enclosures 130B1129
LCP kit Panel mounting kit for all LCPs including fasteners and gasket - without cable 130B1170
Table 4.2: Options can be ordered as factory built-in options, see ordering information.
VLT
®
HVAC Drive Design Guide 4 How to Order
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark 69
4

Danfoss VLT HVAC Specifications

General

Enclosure Rating	IP20, IP21, IP54, IP55, IP66
Storage Temperature Range	-25°C to +70°C
Output Voltage Range	0-100% of supply voltage
Communication Protocols	Modbus RTU, BACnet, Ethernet/IP, Profibus DP
Ambient Temperature Range	-10°C to +50°C (without derating)
Relative Humidity	5% to 95% non-condensing
Altitude	Up to 1000 m without derating
Cooling Method	Air cooled
Application	HVAC systems, Pumps, Fans, Compressors
Voltage Range	200-240 V, 380-500 V, 525-600 V
Frequency Range	0 Hz to 590 Hz
