4How to Order
4.1.1 Drive Configurator
It is possible to design a frequency converter according to the application
requirements by using the ordering number system.
For the frequency converter, you can order standard drives and drives
with integral options by sending a type code string describing the product
a to the local Danfoss sales office, i.e.:
FC-102P18KT4E21H1XGCXXXSXXXXAGBKCXXXXDX
The meaning of the characters in the string can be located in the pages
containing the ordering numbers in the chapter
How to Select Your VLT
.
In the example above, a Profibus LON works option and a General pur-
pose I/O option is included in the frequency converter.
Ordering numbers for frequency converter standard variants can also be
located in the chapter
How to Select Your VLT
.
From the Internet based Drive Configurator, you can configure the right
frequency converter for the right application and generate the type code
string. The Drive Configurator will automatically generate an eight-digit
sales number to be delivered to your local sales office.
Furthermore, you can establish a project list with several products and
send it to a Danfoss sales representative.
The Drive Configurator can be found on the global Internet site:
www.danfoss.com/drives
.
Example of Drive Configurator interface set-up:
The numbers shown in the boxes refer to the letter/figure number of the
Type Code String - read from left to right. See next page!
Product groups
1-3
Frequency Converter
series
4-6
Power rating
8-10
Phases
11
Mains Voltage
12
Enclosure
13-15
Enclosure type
Enclosure class
Control supply volt-
age
Hardware configu-
ration
RFI filter
16-17
Brake
18
Display (LCP)
19
Coating PCB
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24-27
Software language
28
A options
29-30
B options
31-32
C0 options, MCO
33-34
C1 options
35
C option software
36-37
D options
38-39
VLT
®
HVAC Drive Design Guide 4 How to Order
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark
65
4
