Unit features include:
Operation switch (on/off)
Short-circuit and overload protection with test function
Manual reset function
30 Ampere, Fuse-Protected Terminals
3-phase power matching incoming mains voltage for powering auxiliary customer equipment
Not available if two manual motor starters are selected
Terminals are off when the incoming power to the drive is off
Power for the fused protected terminals will be provided from the load side of any supplied contactor, circuit breaker, or disconnect switch.
24 VDC Power Supply
5 amp, 120 W, 24 VDC
Protected against output over-current, overload, short circuits, and over-temperature
For powering customer-supplied accessory devices such as sensors, PLC I/O, contactors, temperature probes, indicator lights, and/or other
electronic hardware
Diagnostics include a dry DC-ok contact, a green DC-ok LED, and a red overload LED
External Temperature Monitoring
Designed for monitoring temperatures of external system components, such as the motor windings and/or bearings. Includes eight universal input modules
plus two dedicated thermistor input modules. All ten modules are integrated into the drive’s safe-stop circuit and can be monitored via a fieldbus network
(requires the purchase of a separate module/bus coupler).
Universal inputs (8)
Signal types:
RTD inputs (including Pt100), 3-wire or 4-wire
Thermocouple
Analog current or analog voltage
Additional features:
One universal output, configurable for analog voltage or analog current
Two output relays (N.O.)
Dual-line LC display and LED diagnostics
Sensor lead wire break, short-circuit, and incorrect polarity detection
Interface setup software
Dedicated thermistor inputs (2)
Features:
Each module capable of monitoring up to six thermistors in series
Fault diagnostics for wire breakage or short-circuits of sensor leads
ATEX/UL/CSA certification
A third thermistor input can be provided by the PTC Thermistor Option Card MCB 112, if necessary
3 VLT HVAC Drive Selection VLT
®
HVAC Drive Design Guide
60
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark
3
