Message Description
e30bd120.11
SO Data Confirmation
Are you sure that you want
to overwrite the safety
parameters including the
level 1 password?
!1(1)
0 RPM 0.00A
e30bd121.11
SO Data Confirmation
Press [OK] to confirm
(commissioning test must be
performed) or [CANCEL] to
abort
!1(1)
0 RPM 0.00A
Decision box for continuing overwriting the existing data or to abort the procedure.
e30bd122.11
Status
SO Custom. completed
SO RESET required!
!1(1)
0 RPM None 0.00KW
!Safe Stop [W68]
Off Remote SO Req.RESET
Press [OK] to complete the customization of the safety option. A reset is required to finalize this
procedure.
e30bd124.11
Status
SO Custom. aborted
SO RESET required!
!1(1)
0 RPM None 0.00KW
!Safe Stop [W68]
Off Remote SO Req.RESET
Press [Cancel] to abort the customization of the safety option. A reset is required to finalize this
procedure.
Table 16: Mismatch Between Safety Parameters in the Safety Option and in the Drive
Message Description
e30bd115.11
SO Param. Selection
Mismatch of SO param.set
detected. Please choose:
!1(1)
0 RPM 0.00 A
SO : Test1234_ 1.00
VLT : SafeSet1_ 1.00
Whenever there is mismatch of safety parameters within the safety option and the drive, this se-
lection form is shown on the LCP. Select between the ‘safety data on safe option’ or the ‘safety
data on frequency converter’ as valid data.
e30bd122.11
Status
SO Custom. completed
SO RESET required!
!1(1)
0 RPM None 0.00KW
!Safe Stop [W68]
Off Remote SO Req.RESET
If selecting [SO:…], the customization of the safety option is completed and a reset is required to
finalize this procedure.
Service and Repair
Installation Guide | VLT® Safety Option MCB 150/151
AQ279747441421en-000101 / 130R0292
72 | Danfoss A/S © 2018.09
