Command Sets
C-10
Function Command
Barcode
Setup barcode parameter ESC [f (n
1
) (n
2
) (k) (m) (s) (v
1
) (v
2
)
(c) (data)
(0 ≤ n
1
, n
2
≤ 255) (n = n
1
+ n
2
X 256)
k: Barcode type
k Barcode type
k value barcode type
B1 hex
B2 hex
B3 hex
B4 hex
B5 hex
B6 hex
B7 hex
B8 hex
BA hex
CODABAR (NW7)
EAN-13
EAN-8
CODE 39
INDUSTRIAL 2 OF 5
INTERLEAVED 2 OF 5
UPC-A
UPC-E
CODE128
m: Module width
m Module width
m unit module dots
00 hex
01 hex
02 hex
03 hex
04 hex
default(2 dots)
2 dots
2 dots
3 dots
4 dots
s: Space width adjustment
s Space width adjustment
“s” is used for fine adjustment for each “spaces” to match the optical conditions.
There is no effect for the “bar” width adjustment.
Range :-3≦s≦3
v
1
, v
2
: Bar length
v
1,
v
2
Bar length
Bar length is described 2 bytes v1 shows lower byte. v2 shows upper bytes.
And bar length is controlled by multiple value of an unit of 1/2160 inch.
Minimum value of v1, v2: 288 dec
vertical pitch : All the input data is rounded to the multiple value.
