96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 100
Disk Enclosure Cabling
120 121 122 110 112 113 100 101 102 103
Figure 116. SFA12KXE/12K-20E Configuration with 20 x SS8460 Enclosures
No. of HD Mini-SAS to HD Mini-SAS Cables Required:
3-meter: 10
6-meter: 10
3-meter for Enclosure Expansion: 20
Controller 1
065022
I/O Module A
Disk Enclosure 11
165122
I/O Module B
065
I/O Module A
Disk Enclosure 12
165
I/O Module B
066001
I/O Module A
Disk Enclosure 13
166101
I/O Module B
066
I/O Module A
Disk Enclosure 14
166
I/O Module B
067021
I/O Module A
Disk Enclosure 15
167121
I/O Module B
067
I/O Module A
Disk Enclosure 16
167
I/O Module B
068003
I/O Module A
Disk Enclosure 17
168103
I/O Module B
068
I/O Module A
Disk Enclosure 18
168
I/O Module B
069013
I/O Module A
Disk Enclosure 19
169113
I/O Module B
069
I/O Module A
Disk Enclosure 20
169
I/O Module B
Controller 0
060002
I/O Module A
Disk Enclosure 01
160102
I/O Module B
060
I/O Module A
Disk Enclosure 02
160
I/O Module B
061012
I/O Module A
Disk Enclosure 03
161112
I/O Module B
061
I/O Module A
Disk Enclosure 04
161
I/O Module B
062010
I/O Module A
Disk Enclosure 05
162110
I/O Module B
062
I/O Module A
Disk Enclosure 06
162
I/O Module B
063020
I/O Module A
Disk Enclosure 07
163120
I/O Module B
063
I/O Module A
Disk Enclosure 08
163
I/O Module B
064000
I/O Module A
Disk Enclosure 09
164100
I/O Module B
064
I/O Module A
Disk Enclosure 10
164
I/O Module B
020 021 022 010 012 013 000 001 002 003
Use 6-meter cables to connect
these ports to the controller
installed in the other rack
Zoning Configuration: 0
