DataDirect Networks SFA12KXE - Figure 51. Release Inner Rail

To Next Page

To Previous Page

Rack Installation

96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 46

Figure 51. Release Inner Rail

Pull Inner Rail Out

Locking Tab

Outer Rail

Middle Rail

Inner Rail
