Disk Enclosure Cabling

96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 98

Figure 114. SFA12KXE/12K-20E Configuration with 5 x SS8460 Enclosures

020 021 022

010 012 013

000 001 002 003

Controller 0

120 121 122

110 112 113

100 101 102 103

Controller 1

013003

I/O Module A

Disk Enclosure 05

113103

I/O Module B

021001

I/O Module A

Disk Enclosure 04

121101

I/O Module B

022000

I/O Module A

Disk Enclosure 03

122100

I/O Module B

020010

I/O Module A

Disk Enclosure 02

120110

I/O Module B

012002

I/O Module A

Disk Enclosure 01

112102

I/O Module B

Zone 1 Zone 2

No Zone

No. of HD Mini-SAS to HD Mini-SAS Cables Required (3-meter): 20

Zoning Configuration: 1
