96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 78
Disk Enclosure Cabling
Figure 94. SFA12KX/12K-40 Configuration with 10 x SS7000 Enclosures
032002 132102
I/O Module A I/O Module B
Disk Enclosure 01
042012
142112
I/O Module A
I/O Module B
Disk Enclosure 02
040010
140110
I/O Module A
I/O Module B
Disk Enclosure 03
050020
150120
I/O Module A
I/O Module B
Disk Enclosure 04
030000
130100
I/O Module A
I/O Module B
Disk Enclosure 05
052022
152122
I/O Module A
I/O Module B
Disk Enclosure 06
031001
131101
I/O Module A
I/O Module B
Disk Enclosure 07
051021
151121
I/O Module A
I/O Module B
Disk Enclosure 08
033003
133103
I/O Module A
I/O Module B
Disk Enclosure 09
043013
143113
I/O Module A
I/O Module B
Disk Enclosure 10
020 021 022 010 012 013 000 001 002 003
Controller 0
030 031 032 033 040 042 043 050 051 052
120 121 122 110 112 113 100 101 102 103
Controller 1
130 131 132 133 140 142 143 150 151 152
No. of HD Mini-SAS to Mini-SAS Cables Required:
3-meter: 20
6-meter: 20
Use 6-meter cables to connect
these ports to the controller
installed in the other rack
Zoning Configuration: 0
