Disk Enclosure Cabling

96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 68

Figure 84. SFA12K-20 Configuration with 3 × SS8460 Enclosure

020 022

010 012

000 002

Controller 0

120 122

110 112

100 102

Controller 1

022000

I/O Module A

Disk Enclosure 03

122100

I/O Module B

020010

I/O Module A

Disk Enclosure 02

120110

I/O Module B

012002

I/O Module A

Disk Enclosure 01

112102

I/O Module B

No. of HD Mini-SAS to HD Mini-SAS Cables Required (3-meter): 12

Zoning Configuration: 1
