System Installation and Configuration
96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 34
Up time shown on the LCD will be different and only the value reported by SFA OS
should be used.
NOTE :
BBU configuration must be done via SFA OS. Do NOT use the LCD menu
on the BBU to change any settings which could result in incorrect
operation.
3. Click to select a BBU.
❖ Verify that the correct Nominal Input Voltage is selected (this is the value
determined during the ATS installation as described in section 8.2, step 3)
❖ Enter the battery manufacturing date for this BBU (Note that the BBU battery pack
should be replaced periodically, refer to the SFA OS User Guide for information on
BBU maintenance)
❖ Click Update to save the changes
4. Select the other BBU and repeat the above step .
5. It is recommended to mark the battery manufacturing date in the subsystem log. From
the Controllers menu, select CLUI Interface. Then enter the MARK SUBSYSTEM TEXT
command. For example, MARK SUBSYSTEM TEXT “MAIN CTLR 0 BBU BAT SET TO
2014:09:13”. Mark the log for both BBUs.
14. Subsystem Configuration
14.1 Verify Physical Disk Status
Select Physical Disks > Show Physical Disks. Verify that all the disks are present and
healthy. If the disks are not visible, refer to the SFA OS User Guide for troubleshooting
information.
14.2 Set Subsystem Attributes
1. From the Subsystem menu, select Set Subsystem Attributes.
2. In the RP Subsystem Name field, enter a name for your subsystem.
3. In the Time Zone field, select a time zone that is appropriate for your site.
4. If you are using NTP, select ON in the Network Time Protocol field. Then in the IP
addresses for NTP field, enter the addresses for up to five NTP servers. Both IPv4 and
IPv6 addresses can be used.
If you are not using NTP, select OFF in the Network Time Protocol field. Then enter
the time for the controller in the Date and Time field.
5. Click Update to save the changes.
NOTE :
If enclosure zoning verification or changes are required, please refer to
the SFA OS User Guide (Enclosure Zoning Configuration) for instructions.
