96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 63

Disk Enclosure Cabling

Figure 79. SFA12K-20 Configuration with 5 x SS7000 Enclosures

020 021 022

010 012 013

000 001 002 003

012002

112102

I/O Module A

I/O Module B

Disk Enclosure 01

Controller 0

120 121 122

110 112 113

100 101 102 103

Controller 1

020010

120110

I/O Module A

I/O Module B

Disk Enclosure 02

022000

122100

I/O Module A

I/O Module B

Disk Enclosure 03

021001

121101

I/O Module A

I/O Module B

Disk Enclosure 04

013003

113103

I/O Module A

I/O Module B

Disk Enclosure 05

No. of HD Mini-SAS to Mini-SAS Cables Required (3-meter): 20

Zoning Configuration: 1
