DataDirect Networks SFA12KXE - Figure 92. SFA12 KX;12 K-40 Configuration with 4 X SS7000 Enclosures

Disk Enclosure Cabling
96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 76
Figure 92. SFA12KX/12K-40 Configuration with 4 x SS7000 Enclosures
020 021 022 010 012 000 001 002
042032 012002
142132 112102
I/O Module A
I/O Module B
Disk Enclosure 01
Controller 0
050040 020010
150140 120110
I/O Module A
I/O Module B
Disk Enclosure 02
052030 022000
152130 122100
I/O Module A
I/O Module B
Disk Enclosure 03
051031 021001
151131 121101
I/O Module A
I/O Module B
Disk Enclosure 04
030 031 032 040 042 050 051 052
120 121 122
110 112
100 101 102
Controller 1
130 131 132
140 142
150 151 152
No. of HD Mini-SAS to Mini-SAS Cables Required (3-meter): 32
Zoning Configuration: 1
