DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 3 -
Electrical equipment should be installed only by qualified
specialist. No responsibility is assured by the manufacturer or
any of its subsidiaries for any consequences resulting from the
non-compliance to these instructions.
Check the controller for cracks and damages due to
transportation. Do not install damaged equipment.
Do not open the controller. There are no serviceable parts inside.
Fuses must be connected to the power supply and phase voltage
inputs, in close proximity of the controller.
Fuses must be of fast type (FF) with a maximum rating of 6A.
Disconnect all power before working on equipment.
When the controller is connected to the network do not touch
terminals.
Short circuit terminals of unused current transformers.
Any electrical parameter applied to the device must be in the
range specified in the user manual. Although the controller is
designed with a wide safety margin, over-range parameters may
reduce lifetime, alter operational precision or even damage the
controller.
Do not try to clean the device with solvent or the like. Only clean
with a dump cloth.
Verify correct terminal connections before applying power.
Only for front panel mounting.
SAFETY NOTICE
Failure to follow below instructions
will result in death or serious injury

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datakom DK-45 and is the answer not in the manual?

Datakom DK-45 Specifications

Power IconPower
supply voltage305 – 460 VAC
supply frequency50 - 60Hz
power consumption< 4 VA
Measurement Inputs IconMeasurement Inputs
voltage input range phase-phase20 - 520 V AC
voltage input range phase-neutral10 - 300 V AC
frequency input range30 - 100 Hz
Relay Outputs IconRelay Outputs
relay output current5A
relay output voltage250V AC
burden< 0.1VA per phase
Operating Environment IconOperating Environment
operating temperature-20°C to +70 °C
storage temperature-40°C to +80 °C
max. relative humidity%95 non condensing
Physical Characteristics IconPhysical Characteristics
dimensions133x107x46mm
panel cutout117x87mm minimum
weight350 gr
