Kyman™ Imager Optical Features (XXX-7XX models)
Imager Optical Features
Max. resolution
1D Codes 0.10 mm / 4 mils
2D Codes 0.17 mm / 6.6 mils
Skew angle ± 40 °
Pitch angle ± 35°
Depth of field*
1D (linear):
X-dimension
mm (mils)
Symbol size
cm (in)
DOF
cm (in)
Code39 0.13 (5) 1.2 (0.47) 8.0 to 15.0 (3.15 to 5.90)
0.50 (20) 3.2 (1.26) 8.0 to 33.0 (3.15 to 12.99)
EAN13 0.33 (13) 3.1 (1.22) 7.5 to 24.5 (2.95 to 9.65)
2D: X-dimension
mm (mils)
Symbol size
cm (in)
DOF
cm (in)
POSTNET 0.5 (20) 4.0 x 0.4 (1.57 x 0.16) 11.5 to 30.0 (4.53 to 11.81)
PDF417 0.13 (5) 1.1 x 0.9 (0.43 x 0.35) 8.5 to 15.5 (3.35 to 6.10)
0.17 (6.6) 1.4 x 1.2 (0.55 x 0.47) 7.0 to 19.0 (2.76 to 7.48)
0.25 (10) 2.2 x 1.8 (0.86 x 0.71) 4.5 to 24.0 (1.77 to 9.45)
QR 0.25 (10) 0.7 x 0.7 (0.28 x 0.28) 7.0 to 15.5 (2.76 to 6.10)
0.38 (15) 1.1 x 1.1 (0.43 x 0.43) 4.5 to 21.0 (1.77 to 8.27)
DataMatrix 0.19 (7.5) 0.8 x 0.8 (0.31 x0.31) 9.0 to 13.0 (3.54 to 5.12)
0.25 (10) 0.8 x 0.8 (0.31 x 0.31) 7.5 to 16.5 (2.95 to 6.50)
0.38 (15) 1.0 x 1.0 (0.39 x 0.39) 6.0 to 22.0 (2.36 to 8.66)
Sensor 640 x 480 pixel element, 2D CMOS array
Illuminator LED array
Wavelength 630~670 nm
LED Safety class Class 1 to EN 60825-1
Aiming System Visible Laser Diode
Wavelength 650 nm
Laser Safety Class 2 EN 60825-1; Class II CDRH
*
Reading distances are measured from the nose of the reader using the test codes. The
reading performances may vary depending on the code printing quality.
