Datalogic Kyman User Manual

CONNECTIONS
2
2.2 WLAN CONNECTION
Kyman™ Wi-Fi 802.11b and Wi-Fi 802.11b/g
1
models can communicate with the host
using the on-board radio frequency module and an Access Point connected to the
host computer.
For models using the WiFi7 radio (7xx-xxx-xxx models), you can find information
about the applet for radio configuration:
http://www.summitdatacom.com/SCU.htm.
To launch this utility you can tap the specific icon if it’s visible on the taskbar or:
1. On Windows CE device, you can open Connections folder or Control Panel from
desktop and select the ‘Summit Client Utility’ icon.
2. On Windows Mobile device, you can select the menu item: Start->Programs-
>Summit and tap the ‘Summit Client Utility’ icon.
A
B
C
Key:
A) Kyman™
B) Access point
C) Host – Application Server
1
Note: unless otherwise specified, the Wi-Fi term is used both for the 802.11b and the 802.11b/g cards.
13

Datalogic Kyman Specifications

General

Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Display number of colors	65536 colors
Internal memory	0.128 GB
Internal memory type	RAM
Compatible memory cards	MiniSD
Processor family	PXA 270
Processor frequency	0.52 GHz
Processor manufacturer	Marvell
Product color	Black
Phone function	No
Wireless technology	IEEE 802.11b/g
Battery capacity	2200 mAh
Keyboard type	53 alphanumeric
I/O ports	3-pin RS232, USB 1.1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating system installed	Windows CE 5.0
Data network	-
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	55 mm
Width	91 mm
Height	238 mm
Weight	550 g
