KYMAN™
4
4.2 REPLACING THE BATTERY PACK
To correctly replace the battery pack, proceed as follows.
1. Turn off the Kyman™.
2. Pull the battery latch down as indicated in the figure below.
3. Remove the battery pack.
Battery Contacts
4. To correctly insert the new battery pack, first insert the bottom and then the
upper part of the battery pack into the slot as indicated in the following figure:
5. Press it back until the battery latch is automatically closed.
80
