KYMAN™
3
A red beam illuminates the code, which is captured and decoded. You will get a good
read.
Linear barcode 2D Matrix symbol
ÌBX3ÉÎ
Relative Size and Location of Aiming System Pattern
The field of view changes its size as you move the reader closer or farther away from
the code. The field of view indicated by the aiming system pattern will be smaller
when the Kyman™ Imager is closer to the code and larger when it is farther from the
code.
Symbologies with smaller bars or elements (mil size) should be read closer to the
unit. Symbologies with larger bars or elements (mil size) should be read farther from
the unit. (See par. 5.1 for further details).
3.4.3 RFID Data Capture
To read or write a tag, place the Kyman™ so that the RFID emission window is in
front of and almost in contact with the tag, then press the SCAN key or the
application defined key.
26

Datalogic Kyman Specifications

General

Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Display number of colors	65536 colors
Internal memory	0.128 GB
Internal memory type	RAM
Compatible memory cards	MiniSD
Processor family	PXA 270
Processor frequency	0.52 GHz
Processor manufacturer	Marvell
Product color	Black
Phone function	No
Wireless technology	IEEE 802.11b/g
Battery capacity	2200 mAh
Keyboard type	53 alphanumeric
I/O ports	3-pin RS232, USB 1.1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating system installed	Windows CE 5.0
Data network	-
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	55 mm
Width	91 mm
Height	238 mm
Weight	550 g
