Datalogic Kyman User Manual

CONNECTIONS
2
NOTE
Suspending the terminal powers off the GSM/GPRS radio and drops the
connection.
When the terminal resumes, if the connection was managed by Microsoft
Internet Explorer, it is automatically restored, otherwise, the radio
connection must be manually re-initialized.
NOTE
The GSM voice capability of this mobile computer has to be addressed
to occasional use, in well covered areas.
If the coverage is poor, the voice quality can be highly affected.
In case of vehicle cradle installations, a good habit is to install the
external microphone to minimize the risk of noises and echoes.
If the coverage is poor, in case of continuous communication, some
degradation of the barcode reading capabilities can be experienced.
2.5 CRADLE CONNECTIONS
The Kyman™ can also communicate via RS232, USB and Ethernet, using various
cradle models.
For further details, refer to the specific cradle model User’s Manual.
17

Datalogic Kyman Specifications

General

Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Display number of colors	65536 colors
Internal memory	0.128 GB
Internal memory type	RAM
Compatible memory cards	MiniSD
Processor family	PXA 270
Processor frequency	0.52 GHz
Processor manufacturer	Marvell
Product color	Black
Phone function	No
Wireless technology	IEEE 802.11b/g
Battery capacity	2200 mAh
Keyboard type	53 alphanumeric
I/O ports	3-pin RS232, USB 1.1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating system installed	Windows CE 5.0
Data network	-
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	55 mm
Width	91 mm
Height	238 mm
Weight	550 g
