KYMAN™
3
The LAN icon will appear on the Taskbar indicating the LAN connection status.
By double tapping on the LAN icon in the
Taskbar, the LANNDS1 applet allows
visualizing the TCP/IP information. Other
information such as the MAC Address is
available by tapping the Details... button.
If it is necessary to set static TCP/IP
parameters, you must open the
LANNDS1 applet from the Network and
Dial-up Connections applet in the
Control Panel. This applet is only visible
when the mobile computer is correctly
inserted into the Ethernet Multi Cradle.
LAN icon
Ethernet LANNDS1 Communications Window
The IP Address belongs to Datalogic Kyman™ while the MAC address is specific to
each cradle slot.
54

Datalogic Kyman Specifications

General

Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Display number of colors	65536 colors
Internal memory	0.128 GB
Internal memory type	RAM
Compatible memory cards	MiniSD
Processor family	PXA 270
Processor frequency	0.52 GHz
Processor manufacturer	Marvell
Product color	Black
Phone function	No
Wireless technology	IEEE 802.11b/g
Battery capacity	2200 mAh
Keyboard type	53 alphanumeric
I/O ports	3-pin RS232, USB 1.1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating system installed	Windows CE 5.0
Data network	-
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	55 mm
Width	91 mm
Height	238 mm
Weight	550 g
