RAPID CONFIGURATION
1
REQUIRED ACCESSORIES:
Item
Accessory
Description Order No.
Matrix 400-x00-0x0 Reader 1
LNS-1116 16 mm C-Mount Lens (Recommended) 93ACC1796
CBX100 Compact Connection Box 93A301067 2
CBX500 Modular Connection Box 93A301068
CAB-MS01 M16-IP67 Cable To CBX (1M) 93A051358 3
CAB-ETH-M01 M12-IP67 Ethernet Cable (1M) (Optional) 93A051346
PG6000 AC/DC Power Supply Unit (EU) 93ACC1718
PG6001 AC/DC Power Supply Unit (UK) 93ACC1719
4
PG6002 AC/DC Power Supply Unit (US) 93ACC1720
LT-410 Coaxial Lighting System 93A401015
LT-511 Dome Lighting System 93A401017
LT-630 Four Bar Lighting System 93A401018
5 (*)
LTC-630 Four Bar Lighting System Controller 93ACC1790
BK-4990 Generic LT Bracket Matrix 400 93ACC1805 7
BK-4410 Coaxial LT Bracket Matrix 400 93ACC1804
(*) The suggested external lighting systems provide a complete solution for DPM parts verification
based on AS9132 and AIM DPM recommendations. The proper lighting environment can be selected
according to the characteristics of the surface on which the code is marked and on the choosen
printing technique; see Paragraph 4.1and 4.2 for further details.
