Enter/Exit Pr
ogramming Mode
Product Reference Guide
97
Code 39 Start/Stop Character Transmission
Enable this option
to enable/disab
le tr
ansmission of Code
39 start and stop
characters
DEF
A
UL
T
$CC3
SS00(
CR)
Code 39 Start/Stop
Character Tr
ansmission =
Don’t Transmit
$C
C3SS01(
CR)
Code 39 Start/St
op Character Transmission = Tra
nsmit
.
Code 39 Full ASCII
Enables/disables the translation of
Code 39 characters to Code 39 full-
ASCII characters.
DEF
A
UL
T
$CC3F
A
00(
C
R
)
Code 39 Full ASCII = Disa
ble
$CC3
F
A
01
(
CR)
Code 39 Full ASCII = Enable
106
108
