Setup
12
PowerScan™ PD9330/PBT9300/PM9300
Attaching the Meta
l Plate to Base
Alternatively
, the mount can be att
ached first to the base,
then both can be
mounted to a wall as described abo
ve.
Figure 5. Attachin
g Mounting Plate to B
ase
Base with Mount attached
System Connections
CA
UTIO
N
Connections should always be made with power off!
The BC9xx0 cradle prov
ides a multi-in
terface connector
and a power supply
connector as
shown:
Power Supply
Multi-Interf
ace Connecto
r
21
23
