Enter/Exit Pr
ogramming Mode
Product Reference Guide
27
Stop Bits
Set the number of stop bit
s to ma
tch host device
requirements. See
page
254
for more informatio
n on
this feature.
DEF
A
UL
T
$CR2ST00(
CR)
1 Stop Bit
$CR2ST01(CR)
2 Stop Bits
Parity
This feature specifies par
ity required for sending an
d receiving data
. Select
the parity type according to
host devi
ce requirements. See
page
254
for
more information.
DEF
A
UL
T
$CR2P
A00(CR)
Parity = None
$CR2P
A01(CR)
Parit
y = Even
$CR2P
A02(CR)
Parity = Odd
