Datalogic PowerScan PBT9500 Software Reference Guide

ETHERNET/IP™: Industrial Protocol
32 BC9180™ Base Station/Charger
Identity Object (01
HEX -
1 Instance)
The following tables contain the attribute, status, and common services
information for the Identity Object.
Table 4.Identity Object (01
HEX -
1 Instance)
Instance
Attribute
ID
Name
CIP
Data Type
Data
Value
Access
Rule
Class
(Ins
tance
0)
1 Revision UINT 1 Get
Instance 1 1 Vendor number UINT
850
Get
2 Device type UINT 43 Get
3 Product code number UINT 9500 Get
4 Product major revision
Product minor revision
USINT
USINT
1.01 Get
5 Status WORD See Get
6 Serial number UDINT Unique 32 bit value
(Last 4 of MAC ID)
Get
7 Product name SHORT
STRING32
Wireless Barcode
Reader
Get
100 Produc
t model number SHORT
STRING32
“P
roduct Model
Number”
Get
Table 5. Identity Object’s common services
Service code
Implemented for
Service name
Class level Instance level
05
Hex
No Yes Reset
0E
Hex
Yes Yes Get_Attribute_Single
10
Hex
No Yes Set_Attribute_Single
Message Router Object (02HEX - 1 Instance)
***No supported services or attributes***

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
