Datalogic PowerScan PBT9500 Software Reference Guide

ETHERNET/IP™: Industrial Protocol
38 BC9180™ Base Station/Charger
ModbusTCPMapping
Holding Register
(4x)
Description
Data
Type
Class
ID
Inst
ID
Attr
ID
1 – 2 Discrete Inputs DWORD 0x64 0x01 1
3 – 4 Barcode Scanner Status DWORD 0x64 0x01 2
5 Item Sequence Number UINT 0x64 0x01 3
6 Item Total Size UINT 0x64 0x01 4
7 Fragment Sequence Number UINT 0x64 0x01 5
8 Fragment Size UINT 0x64 0x01 6
9 – 233 Fragment Data USINT[450] 0x64 0x01 7
234 – 235 Discrete Outputs DWORD 0x64 0x01 8
236 Last Item Sequence Number UINT 0x64 0x01 9
237 Last Fragment Sequence Num-
ber
UINT 0x64 0x01 10
238 – 239 Output Status DWORD 0x64 0x01 11
240 Output Item Sequence Number UINT 0x64 0x01 12
241 Output Item Total Size UINT 0x64 0x01 13
242 - 466 Output Data USINT[450] 0x64 0x01 14
467 Last Output Item Sequence
Number
UINT 0x64 0x01 15

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
