Datalogic PowerScan PBT9500 Software Reference Guide

Ethernet Host Interface Operation
10 BC9180™ Base Station/Charger
Service: Webserver
The Host can receive a dynamic page that is updated with all newly received
labels from the BC9180™ by using any commercial Web Browser and access-
ing it at the URL:
http://<BC9180™_IP_Address>
Figure 4. Webserver Service
NOTE
You can also use Aladdin software to obtain the IP address of the cradle, after
the cradle is connected to the network.
The BC9180™ cradle can support multiple clients accessing the Web Server
at the same time.

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
