Datalogic PowerScan PBT9500 Software Reference Guide

Ethernet Software Reference Guide 47
Appendix A
Standard Defaults
The most common configuration settings are listed in the “Default” col-
umn of the table below. Page references are also provided for feature
descriptions and programming bar codes for each parameter. A column
has also been
provided for recording of your preferred default settings
for these same configurable features.
Table 16. Standard Defaults
Parameter Default Your Setting
ETHERNET HOST INTERFACE ONLY
ETH Standard
HostInterface
DHCP Client
Enable
Static IP Address
1
92.168.187.31
Subnet Mask
255.255.255.0
Gateway Address
192.168.187.254
DNS1 Address
0.0.0.0
DNS2 Address
0.0.0.0
Device Name
BC9180‐433(910)(BT)[BASE_SERIAL_NUMBER]
Data Socket Port
51000
Web Server Security
Disable
Web Server Password
password

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
