ETHERNET/IP™: Industrial Protocol
34 BC9180™ Base Station/Charger
Table 8. O2T (Output) Assembly Data Format
Byte Description Data Type Class ID Inst ID Attr ID
0 – 3 Discrete Outputs DWORD 0x64 0x01 8
4 – 5 Last Item Sequence Number UINT 0x64 0x01 9
6 – 7 Last Fragment Sequence
Number
UINT 0x64 0x01 10
8 – 11 Output Status DWORD 0x64 0x01 11
12 – 13 Output Item Sequence Num-
ber
UINT 0x64 0x01 12
14 – 15 Output Item Total Size UINT 0x64 0x01 13
16 – 465 Output Data USINT[450] 0x64 0x01 14
466 – 467 Reserved (for 32-bit align-
ment)
UINT N/A N/A N/A
Table 9. Assembly Object’s common services
Service code
Implemented for
Service name
Class level Instance level
0E
Hex
Yes Yes Get_Attribute_Single
10
Hex
Yes Yes Set_Attribute_Single
Connection Manager Object (06HEX)
***No supported services or attributes***

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
