Datalogic PowerScan PBT9500 Software Reference Guide

ETHERNET/IP™ Object Model
Ethernet Software Reference Guide 37
Barcode Scanner Object (64
HEX -
1 Instance)
The following tables contain the attribute and common services informa-
tion for the Barcode Item Object.
Table 14. Unit Object (64
HEX -
1 Instance)
Instance Attribute ID Name Data Type
Data
Value
Access
Rule
Class
(Instance 0)
1 Rev
ision UINT 1 Get
100 Max Item Data Buffer Size UINT 65535 Get
101 Max Fragment Data Buffer
Size
UINT 450 Get
Instance 1 1 Discrete Inputs DWORD Varies Get
2 Barcode Scanner Status DWORD Varies Get
3 Item Sequence Number UINT Varies Get
4 Item Total Size UINT Varies Get
5 Fragment Sequence Number UINT Varies Get
6 Fragment Size UINT Varies Get
7 Fragment Data USINT[450] Varies Get
8 Discrete Outputs DWORD Varies Get / Set
9 Last Item Sequence Number UINT Varies Get / Set
10 Last Fragment Sequence
Number
UINT Varies Get / Set
11 Output Status DWORD Varies Get / Set
12 Output Item Sequence Num-
ber
UINT Varies Get / Set
13 Output Item Total Size UINT Varies Get / Set
14 Output Data USINT[450] Varies Get / Set
15 Last Item Sequence Number UINT Varies Get
Table 15. Barcode Scanner Object’s common services
Service code
Implemented for
Service name
Class level Instance level
0E
Hex
Yes Yes Get_Attribute_Single
10
Hex
No Yes Set_Attribute_Single

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
