Datalogic PowerScan PBT9500 Software Reference Guide

ETHERNET/IP™ Object Model
Ethernet Software Reference Guide 39
Fragmentation Example
To Datalogic barcode scanner from EIP Client
To ETHERNET/IP™ Client from Datalogic Barcode Scanner
Last Item Sequence Number
Last Frag- ment Sequence Number
Item Sequence Number
Fragment Sequence Number
Item Size Frag-
ment Size
Fragment Data Buffer
Description
0 0 0 0 0 0 NULL Power Up
1 1 2000 480 [0-479] Datalogic sends fragment 1
0 1 EIP Client acknowledges fragment 1
1 2 2000 480 [480-959] Datalogic sends fragment 2
0 2 EIP Client acknowledges fragment 2
1 3 2000 480 [960-1439] Datalogic sends fragment 3
0 3 EIP Client acknowledges fragment 3
1 4 2000 480 [1440-1919] Datalogic sends fragment 4
0 4 EIP Client acknowledges fragment 4
1 5 2000 80 [1920-1999] Datalogic sends fragment 5
1 5 EIP Client acknowledges whole Item Data Buffer

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
