Datalogic SC6000 User Manual

SOFTWARE CONFIGURATION
47
3
Parameter
Default Setting
Operating Modes
Max Encoder Delay for Code
400
Max Consecutive Delayed Codes
3
Max Safe Resync for Node
3
Bidirectional
Disabled (unchecked)
Encoder Divided by 2
Disabled (unchecked)
Beam Shutter Triggered
Disabled (unchecked)
Protocol Index
Disabled (unchecked)
Hybrid System
Disabled
Reading System Layout
Enable Automatic Replacement (D.A.R.P)
Enabled (checked)
Data Communication Settings
Host Application Protocol Type
Standard
Data Format
Header TX Start
With Data
Termination After No Read Message
Enabled (checked)
Code Identifier
Disabled
Standard Parameters
Header String
<STX>
Code Position
Disabled (unchecked)
Code Direction Identifier Enable
Disabled (unchecked)
Termination String
<CR><LF>
Data Packet Separators
<CR><LF>
Code Field Length Setting
Variable Length
Multidata
Address Tx
Disabled (unchecked)
Main Serial Port
Data TX
Enabled (checked)
Heartbeat
Disable
Parameters
Main Port Communication Mode
Standard
Main Port Electrical Interface
RS232
Handshake
None
Baud Rate
9600
Parity
None
Data Bits
8
Stop Bits
1
Auxiliary Serial Port
Data TX
Enabled (checked)
Heartbeat
Disable
Pass Through
Disabled (checked)
Parameters
Baud Rate
115200
Parity
None
Data Bits
8
Stop Bits
1
