Generating Label Formats
154 Class Series 2 Programmer’s Manual
Field Valid Inputs Meaning
eee
000 to 999 (000 to 099 Reserved), A04 to A72, x04 – x72,
Where x is an upper case letter; see Appendix H.
Font / Size
ffff
0000 to 9999 Row
gggg
0000 to 9999 Dependent upon printer. See Appendix K. Column
jj…j
Valid ASCII character string up to 255 characters followed by a
termination character.
Data
Table 8-7: Smooth Font Record Structure
3: Scalable Fonts
The Smooth Scalable Font Technology is licensed from AGFA. Both Microtype* and
TrueType (.TTF) Scalable Font file formats are supported. The eee field identifies
the scalable font, and data type – normal (binary) or Hex ASCII. Uppercase S or U
– binary, lowercase u – Hex ASCII (see Appendix H). Values S00 to S9z, and U00 to
U9z (u00 to u9z), select a scalable font. S00 and S01 are used for the standard
internal (resident) fonts on display-equipped models, while S01 is used for the
standard internal (resident) font on non-display models.
Field Valid Inputs Meaning
a
1, 2, 3 and 4 Rotation
b
9 Fixed Value
c
1 to 9, A to Z, and a to z Width Multiplier
d
1 to 9, A to Z, and a to z Height Multiplier
eee
S00 to Szz, U00-Uzz, u00-uzz Font Data Type
ffff
0000 to 9999 Row
gggg
Dependent upon printer. See Appendix K. Column
hhhh
P004-P999, 0016-4163**
Character Height;
points, dots
iiii
P004-P999, 0014-4163**
Character Width;
points, dots
jj…j
Valid ASCII character string up to 255 characters followed by a
termination character.
Data
* I-Class supports Intellifont.
**Character sizes are resolution dependent, as indicated in the following table.
Table 8-8: Scalable Font Record Structure
