Datamax MP Compact4 Mark II Programmer's Manual

Appendix U – Display Icon Key and Control Panel Button Sequence Functions
310 Class Series 2 Programmer’s Manual
Control Panel Button Sequences
Three Button / Three LED Control Panel
Function Printer Mode Button Sequence
Pause Idle PAUSE
Feed / Clear Fault Idle FEED
Cancel Idle CANCEL
Soft Reset Idle PAUSE & CANCEL (or Long CANCEL)
Print Test Label Idle PAUSE & FEED
Print Configuration Label Idle FEED & CANCEL
Print Network Label Idle PAUSE, FEED, & CANCEL
Quick Calibration Idle Long FEED
Empty Calibration Idle Long PAUSE & FEED
Media Calibration * CANCEL
Reset Database to Configuration File * PAUSE & FEED
Menu / Setup * PAUSE
Reset firmware (but not Ethernet
parameters)
* PAUSE, FEED, & CANCEL
Reset firmware (and Ethernet
parameters)
* FEED & CANCEL
Hex Dump Mode Power-Up Hold FEED
Enter Boot Mode Power-Up Hold PAUSE & CANCEL
*Power “On” the printer then when the LEDs illuminate press and hold indicated the Button Sequence
until the LEDs extinguish.

Datamax MP Compact4 Mark II Specifications

General

Brand	Datamax
Model	MP Compact4 Mark II
Category	Printer
Language	English
