Datamax MP Compact4 Mark II Programmer's Manual

Immediate Command Functions
12 Class Series 2 Programmer’s Manual
SOH A Send ASCII Status String
This command allows the host computer to check the current printer status. The printer
returns a string of eight characters, followed by a carriage return. Each character (see
below) indicates an associated condition, either true (Y) or false (N). Byte 1 is
transmitted first. See <SOH>F.
Syntax:
<SOH>A
Sample:
<SOH>A
Printer Response:
abcdefgh<CR>
Where:
Possible
Values
Interpretation
Transmit
Sequence
a
-
Y/N Y = Interpreter busy (imaging) 1
b
-
Y/N Y = Paper out or fault 2
c
-
Y/N Y = Ribbon out or fault 3
d
-
Y/N Y = Printing batch 4
e
-
Y/N Y = Busy printing 5
f
-
Y/N Y = Printer paused 6
g
-
Y/N Y = Label presented 7
h
-
Y/N Y = (Internal) Rewinder out or fault 8
Table 3-1: ASCII Status Bytes
SOH a Send ASCII Extended Status String
This command allows the host computer to check an extended current printer status.
The printer returns a string of seventeen characters, followed by a carriage return. Most
characters (see below) indicate an associated condition, either true (Y) or false (N). Byte
1 is transmitted first. See <SOH>F.
Syntax:
<SOH>a
Sample:
<SOH>a
Printer Response:
abcdefgh:ijklmnop<CR>

Datamax MP Compact4 Mark II Specifications

General

Print Method	Direct Thermal
Maximum Print Width	4.1 inches (104 mm)
Media Type	die-cut, fan-fold, tag stock
Media Thickness	0.0025" (0.0635 mm) to 0.01" (0.254 mm)
Media Roll Diameter	5 inches (127 mm) max
Ribbon Length	984 feet (300 meters)
Processor	32-bit RISC
Interfaces	USB, Serial RS232
Optional Interfaces	Wireless (802.11 b/g/n), Bluetooth
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	41 to 104°F (5 to 40°C)
Supported Barcode Types	UPC-A, UPC-E, EAN-13, EAN-8, Code 39, Code 128, Interleaved 2 of 5, Codabar, PDF417, Data Matrix, QR Code, MaxiCode, Aztec
Print Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Ribbon Width	1" (25.4 mm) to 4.3" (110 mm)
