System-Level Command Functions
Class Series 2 Programmer’s Manual 31
STX V Software Switch Settings
This command controls the printer options, where the appropriate value allows the
option(s) to be “On” or “Off.” Each option has a corresponding bit whose value is “1”
when enabled. The tables below indicate the bit assignments and corresponding
command value needed to enable the desired option(s). Printer options are set by
entering selections through the menu. The software setting command allows two of
these option settings to be modified without returning to the menu.
Syntax:
<STX>Vn
Where:
n
- Is a single digit ASCII numeric value from 0-F. The
value of n is used to override the power-up option
settings. Reset or power-up returns the printer to the
original settings.
Sample:
<STX>V5
The sample above corresponds to setting Bits 0 and 2, creating a
command value of 5. When applied, this enables the Present
Sensor and Cutter options.
Bit Assignment Printer Option
0 Cutter
1 N/A
2 Present Sensor
3 N/A
Table 4-1: Software Switch Bit Assignment
Use the bit assignment table above to determine the command value n in the binary
table below (e.g., the command value 5 sets the bits 0 and 2 to “1”).
Command Values for Bits Assigned
Bit
n Value
3 2 1 0
0 0 0 0 0
1 0 0 0 1
4 0 1 0 0
5 0 1 0 1
Table 4-2: Software Switch Binary

Datamax MP Compact4 Mark II Specifications

General

Print Method	Direct Thermal
Maximum Print Width	4.1 inches (104 mm)
Media Type	die-cut, fan-fold, tag stock
Media Thickness	0.0025" (0.0635 mm) to 0.01" (0.254 mm)
Media Roll Diameter	5 inches (127 mm) max
Ribbon Length	984 feet (300 meters)
Processor	32-bit RISC
Interfaces	USB, Serial RS232
Optional Interfaces	Wireless (802.11 b/g/n), Bluetooth
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	41 to 104°F (5 to 40°C)
Supported Barcode Types	UPC-A, UPC-E, EAN-13, EAN-8, Code 39, Code 128, Interleaved 2 of 5, Codabar, PDF417, Data Matrix, QR Code, MaxiCode, Aztec
Print Resolution	203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Ribbon Width	1" (25.4 mm) to 4.3" (110 mm)
