Appendix F – Bar Code Summary Data
202 Class Series 2 Programmer’s Manual
203 DPI Resolutions 300 DPI Resolutions 400 DPI Resolutions 600 DPI Resolutions
Font
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
W1p N/A N/A N/A N/A N/A N/A N/A N/A
W1q .40 2 .40 4 .40 4 .40 6
W1R 1.40 2 1.40 4 1.40 4 1.40 6
W1S/W1s 0.40 6:2 0.40 9:4 0.40 12:4 0.40 18:6
W1t .40 6:2 .40 9:4 .40 12:4 .40 18:6
W1Y/ W1y .40 2 .40 4 .40 4 .40 6
W1Z/W1z N/A N/A N/A N/A N/A N/A N/A N/A
Table F-2: Bar Code Default Data

Some bar codes will be sensitive to Label Command “D”; see Label Formatting Commands for details.
