Appendix R – Line Mode
294 Class Series 2 Programmer’s Manual
<STX>L
PG
SG
D11
15110000160001099999999999999999999999999999999999
U
151100001200010FIXED FIELD #1
15110000080001099999999999999999999999999999999999
U
151100000400010FIXED FIELD #2
15110000000001099999999999999999999999999999999999
U
Q0001
sCDMXFRM
To print a label, the attached device now only has to send the data. Sample data in this
example is as follows:
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA[CR]
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB[CR]
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC[CR]
The sample data will print the following label (layout and font are approximations):
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA
FIXED FIELD #1
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB
FIXED FIELD #2
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC
If multiple labels are needed, data for the labels can be sent at the same time. Sample data
for two labels:
TEST DATA AAAAAAAAAAAAAAAAAAAAAAAAA[CR]
TEST DATA BBBBBBBBBBBBBBBBBBBBBBBBB[CR]
TEST DATA CCCCCCCCCCCCCCCCCCCCCCCCC[CR]
TEST DATA DDDDDDDDDDDDDDDDDDDDDDDDD[CR]
TEST DATA EEEEEEEEEEEEEEEEEEEEEEEEE[CR]
TEST DATA FFFFFFFFFFFFFFFFFFFFFFFFF[CR]
The sample data will print the following two labels (layout and typeface are
approximations):
