2.2 Unpacking System Components
See the list of standard components for an AP20 shipment, on page 11. The exact contents may vary,
depending on the options you have ordered.
Note: Refer to the actual packing slip from your order to verify the contents of your shipment.
Contact Datasat Digital Entertainment immediately if items listed on your packing slip are
missing.
2.2.1 Preliminary Inspection
Note: Before installing the AP20 unit, take a complete inventory of system components to minimize
problems or questions during installation. Additionally, save all packing materials until installation is
complete in case you need to return parts to the factory.
2.3 Installation Overview
The AP20 chassis is the main component of the AP20 system. Installation procedures include:
 Mounting the AP20 chassis in a rack
 Connecting the AP20 unit to other equipment
 Connecting the AP20 unit to a power supply
Device Disconnect: The power outlet shall be installed near the equipment and shall be
easily accessible, in order to quickly disconnect power.
2.4 AP20 Rear Panel Connections
Figure 12 shows the rear panel of the AP20. Table 3 gives a description of each connector shown in the
figure. For specific information on the pin-outs of each connector, please see Appendix A of this manual.
