AP20 Installation and Operating Guide Page 79
AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25
On – Use when center channel speaker is not available. The information from the center
channel plays on the left and right channels. Note: This is only in effect while playing
audio through the decoder.
DTS Neo:6 Option
Off
Music – Neo:6 Music keeps the front left and right channels intact while synthesizing the
center and surround channels from the 2-channel source.
Cinema – Neo:6 Cinema creates 6.1-channels, from 2-channel movie sources, by removing
in-phase information from the Left/Right signals and using it to create the center channel;
and extracting out-of-phase information which is sent to the surround channels.
Note: DTS Neo:6 is applied only when receiving 2-channel stream.
Misc Options
Direct Mode – Processing is disabled.
Disable Surround Remap – When enabled, this option will not remap the playback of 5.1
content to 7.1 speaker configuration.
DTS LFE +10dB – Removes the +10dB LFE boost applied to the LFE channels when
playing DTS decoded audio. This option may be required for older DTS audio discs.
4.3.7 EQ Setup
Menu (System) > Formats > Audio EQ Setup
Figure 54. Audio EQ Setup Screen
4.3.7.1 Current Audio EQ
This drop-down list allows you to select from the list of available EQ setups. The selection will become
the current audio equalization setup.
