Audio EQ:
 Dirac: Enabled or disabled depending on setup and calibration
 Third Octave EQ: Calibrated adjustment made by qualified technician
 Parametric Equalization: Calibrated adjustment made by qualified technician
2.8 Factory Presets
The AP20 factory settings include formats for Digital Cinema and Nonsync as described in the table
below.
Table 4. AP20 Factory Presets
Format
Name
Assigned
Button
Signal Source EQ Set Channel
Profile
Digital
Cinema
1 Digital In (1-16) EQ1 Profile1
Nonsync 2 Nonsync 1 EQ1 Profile1
The default EQ set is named EQ1 and includes all EQ settings flat and all filters off. This EQ set may be
used and altered during the theater setup process. The default channel profile is Profile1, which includes
the default 6 channel assignments and trim values flat.
See appendix F for Optical Film Card option factory presets.
2.8.1 Preset Formats
The default formats appear in the Audio Format Setup screen under the pull down menu for Current
Audio Format.
To create a format with the same name and source not shown in the table, go to the <Edit Formats>
button on the upper right of this same menu. Any existing format can be copied to a new format. Any
of the format settings may be changed after the format is copied from another. You can also rename or
delete existing formats.
