AP20 Installation and Operating Guide Page 4
AP20 Installation & Operating Guide Document # 9301H39200 Ver. 1.25
TABLEOFCONTENTS
INTRODUCTION 6
PART 1: OPERATION 13
1.0 OPERATING AP20 14
1.1 HOW-TO PROCEDURES – OPERATIONS 14
1.2 FRONT PANEL CONTROLS AND INDICATORS 15
1.3 POWERING ON THE AP20 PROCESSOR 16
NAVIGATING THROUGH THE MENUS 17
1.4 THE HOME SCREEN 18
1.4.1 ADJUSTING THE FADER 18
1.4.2 BOOTH MONITOR VOLUME 19
1.4.3 MANUAL AUTOMATION 20
1.5 TROUBLESHOOTING (OPERATION) 21
PART 2: INSTALLATION AND SETUP 23
2.0 INSTALLATION AND SET UP 25
2.1 INSTALLATION CHECKLIST 25
2.2 UNPACKING SYSTEM COMPONENTS 26
2.2.1 PRELIMINARY INSPECTION 26
2.3 INSTALLATION OVERVIEW 26
2.4 AP20 REAR PANEL CONNECTIONS 26
2.5 CHASSIS RACK MOUNTING AND CONNECTION 28
2.5.1 RACK MOUNT RECOMMENDATIONS 28
2.5.2 POWER SUPPLY 28
2.6 NAVIGATING THE MENUS 29
2.7 ABOUT FORMATS 29
2.7.1 CREATING AN AUDIO FORMAT 31
2.8 FACTORY PRESETS 32
2.8.1 PRESET FORMATS 32
2.8.2 DEFAULT EQ 33
2.8.3 DEFAULT CHANNEL PROFILES 33
2.9 AP20 CONFIGURATION AND SETUP 34
2.9.1 EQUIPMENT REQUIREMENTS 34
2.9.2 SETTING AND ADJUSTING AUDIO OUTPUT LEVELS 34
2.9.3 THEATER EQUIPMENT CHECK 35
2.9.4 ASSIGN CHANNELS ON AP20 35
2.9.5 HEARING IMPAIRED OUTPUT 37
2.9.6 VERIFY CHANNEL ASSIGNMENTS IN AUDITORIUM 37
2.10 B CHAIN ALIGNMENT USING 1/3 OCTAVE EQ 37
2.10.1 SET LEVELS TO ESTABLISH A BASELINE 39
2.10.2 PERFORM THE EQ 40
2.11 SUBWOOFER EQ – PARAMETRIC EQ 42
2.12 COPY EQ SET TO ANOTHER EQ SET 43
2.13 FINAL ADJUSTMENTS 44
2.14 COPY FORMAT 44
2.15 SETTING UP MULTIPLE SCREENS 44
2.16 USING DIRAC LIVE® TO TUNE THE AUDITORIUM 44
