Datascope Accutorr Plus - Accutemp IR, Infrared Thermometer (Optional Module); Accutemp IR Mounting Cradle

Disassembly Instructions Repair Information
3 - 14 0070-10-0691 Accutorr Plus Service Manual
2. Remove J2 and J3 connectors from the circuit board to front panel input receptacle.
NOTE: The connectors may be reversed or interchanged
without affecting final function.
3. Remove the three screws securing the circuit board and anti static shield. Remove the
assembly.
3.6.12 AccuTemp IR, Infrared Thermometer (optional module)
The AccuTemp IR has no user accessible adjustments or replaceable parts, except for the 9
Volt battery. If problems arise, contact Technical Service.
3.6.13 AccuTemp IR Mounting Cradle
The mounting cradle has no adjustments or replaceable parts. The mounting cradle houses
a small circuit board and a photocell sensor.
