3.7.2 Power Supply Connectors
3.7.2.1 AC input connector, J-2
3.7.2.2 DC output connector, J-3
7 Out TTL, control line CS_LCD*
8 Out TTL, address line A_DAMP_CONN<2>
9 In -10V supply -10V
10 Out TTL, LCD reset RESETSRV*
11 In/Out TTL, data line D_DAMP_CONN<0>
12 In/Out TTL, data line D_DAMP_CONN<1>
13 In/Out TTL, data line D_DAMP_CONN<2>
14 In/Out TTL, data line D_DAMP_CONN<3>
15 In/Out TTL, data line D_DAMP_CONN<4>
16 In/Out TTL, data line D_DAMP_CONN<5>
17 In/Out TTL, data line D_DAMP_CONN<6>
18 In/Out TTL, data line D_DAMP_CONN<7>
19 Out ground DGND
20 N/C N/C N/C
21 Out TTL Level A_DAMP_CONN<3>
22 Out TTL Level A_DAMP_CONN<4>
23 Out TTL Level DSP_CONT*
24 Out TTL Level A_DAMP_CONN<5>
25 Out +15VDC +15VV
26 Out -15VDC -15VV
PIN # INPUT/OUTPUT DESCRIPTION NAME
PIN # FUNCTION PIN # FUNCTION
1 AC Ground 4 N/C (pin removed)
2 N/C (pin removed) 5 AC Hot
3 AC Neutral
PIN # FUNCTION PIN # FUNCTION
1 +5 V 8 Common
2 +5 V 9 +12.5 V
3 Common 10 STDBY
4 Common 11 ACON*
5 +15 V 12 +12-15ON*
